Knitting Machine Troubleshooting Hints

Brother knitting machines have an ongoing punch card reader problem (timing belt/punch card reader mechanism) that can occur with Brother (and KnitKing) punch card machines. Especially vulnerable is the KH-260 (or KnitKing PC) . It mostly occurs when the patterning mechanism has not been used in a while or has not been serviced for some time. It needs to be kept oiled. Cleaning and lubricating your machine should be done regularly at least once a year and more often if your machine is used often as it is susceptible to lint and yarn fuzz contamination. Oiling the timing belt sprocket...

Questions often asked by Studio/Singer/White and Silver Reed Knitters. Point Cams, Magid Cams and Yarn Separators. What are they and what am I supposed to do with them? Magic Cams, Point Cams and Yarn Separators are used for knitting an isolated motif, usually referred to as "Single Motif" in your manual. Magic Cams screw onto the carriage, one to the left and one to the right, just behind the side levers. Magic Cams tell your carriage that you want to knit one single pattern some where on your garment. Point Cams are like the margins of a typewriter, Point cams...

AVOID A MAJOR PROBLEM - Knitting Machine Tips  By Judy One of the biggest and most frustrating problems a machine knitter can face is that of a damaged needle channel. A damaged channel can be seen as a small nick our gouge in the side of the needle channel. This slight gouge will cause the needle to be stopped as it is trying to move up in the channel. This will bring the locks to a sudden and complete stop. In other words, the locks jam. The cause of a bad needle channel is simple.  As the needle tries to...

The problems listed here are the most common knitting machine problems. If you still have questions and are in the USA, you can text us at 321-961-2801 (10am-4pm Monday thru Saturday - Eastern time zone) and we will get back to you ASP.  Also, you need to E-mail us - Email to knittingcloset33@gmail.com and we will reply as soon as we are able. If you are in the USA,  please include a phone number and we will do out best to call you back - just let us know a time slot that is the best for you. Thank you!

Take the belt connecting pin such that it is on the inside and place it on the belt cover (right grove fitting onto the rotary encoder as shown in the figure 14-14) Turn the rotary encoder pulley by the rib and pull out the rear tail side. When turning the rotary encoder, be certain not to turn it by the comb. On the left side, similarly, place the belt so that the long hole in it is matched to the notch in the pulley and pull out to the rear rail side. Pull both ends of the belt together so...
